The latest inhaler in our range: The equosonic free is a powerful ultrasonic nebulizer that is mobile as an "all-in-one solution" and comes to you in a practical transport case. We have designed our best ultrasonic technology to be as compact as possible and combined it with an ergonomic mask. Thanks to the two-chamber system, saline, brine, and medications can be nebulized very hygienically. This keeps cleaning simple and straightforward. Our inhalation capsules ensure very low wear on the device, so follow-up costs are very low.

As a world first, there is an additional add-on for our new inhaler. With the new inhalation sticks, therapy can be made even more effective. Various types, such as eucalyptus, thyme, sage, and lavender, can support aromatherapy for different issues. The inhalation sticks are not included in the delivery. Find your favorite variety here or try all varieties right away.

The package includes:

• equosonic free with mask and technical unit
• 2 inhalation capsules
• 20 ml measuring cup
• 2 x 20 ml syringes
• 2 x spikes
• Fixing rubber band
• Nebulizer hose including connection nozzle and special angle adapter free
• Fan hose including connection nozzle and special angle adapter free
• Disinfectant Innowatech Anolyte-B 1000 ml
• Pharmasole 1000 ml, 4% salt concentration
• Transport case
• Battery bag
• Powerful battery and charger (for 5-8 inhalations)
• 2 x strap buckle with quick release and carabiner
• Padding for mask (normal size)
• 2 x closure plugs for mask bottom and inhalation stick opening

Technical data:

• Particle size 0.5-5 microns (fully lung-penetrating)
• Nebulizer output approx. 2-3 ml/min
• Power approx. 20 watts
• The device weighs approx. 1.4 kg and is very comfortable to carry due to its geometry and weight distribution

What else is needed to start:

• Contact liquid: 30 ml distilled water / alternatively 30 ml tap water (make sure no lime deposits form)

Which size suits me?

The equosonic free is currently available in two sizes. For smaller animals with short noses, we recommend the pony mask, e.g., ponies, Haflingers, Icelandic horses. For horses from the size of thoroughbred or warmblood, we recommend the mask in the standard size. For very broad noses, we recommend purchasing our large padding additionally.

The Technology

Ultrasonic nebulizers are used for nebulizing inhalation solutions in the respiratory application area. Aerosol generation occurs via mechanical vibrations at a frequency of 1.7 MHz, which are produced in distilled water (contact water). These vibrations are generated by piezoceramic components that convert electrical energy into mechanical vibrations.

To physically separate the nebulizer and nebulization unit, an aquapak® system is used within the contact liquid. The mechanical vibrations are transmitted through its base and spread in the inhalation liquid. Fine capillary waves form on the surface of the NaCl or inhalation solution, which increase with rising excitation frequency and enable aerosol formation.

The ultrasonic nebulizers of the equosonic series produce particle sizes of approx. 0.5 to 5 µm with a nebulization output of up to 6.5 ml/min. The generated aerosol spectrum can be distributed in different areas of the respiratory tract depending on particle size, breathing technique, and application situation.

Compared to technically simpler compressor nebulizers, ultrasonic nebulizers work with high-frequency mechanical vibrations, which can produce fine aerosol particles. In the literature, particle sizes under 5 µm are described in connection with applications in respiratory inhalation.

Over 95% of the surface of the respiratory system is located below the larynx. The bronchial system has extremely fine branches with very small diameters. Therefore, particle size plays a crucial role in the distribution of aerosol particles within the airways.

The ultrasonic nebulizers of the equosonic Privat, equosonic Klinik, and equosonic free series operate with a ceramic membrane frequency of 1.7 MHz and produce aerosol particles in a size range of approx. 0.5 to 5 µm.

For the most even distribution of the aerosol, calm and relaxed breathing during application is recommended. Therefore, the animal should stand as still as possible during inhalation and not be moved intensively immediately before or directly after the application.

The Open Mask

Our inhalation mask is made of high-quality, food-safe PE plastic and does not require additional valves. Unlike closed mask systems, the animal does not have to actively inhale the aerosol mist. Instead, the generated mist is continuously fed into the mask via a ventilation system.

The open system allows for the most natural and relaxed breathing possible during application. Calm breathing can help aerosol particles distribute evenly in the airways. Due to the lower breathing speed during relaxed breathing, fine aerosols can also reach deeper areas of the respiratory tract.

The inhalers continuously introduce the generated aerosol into the mask while the animal can inhale and exhale the mist in a calm breathing situation.

Inhalation During Movement

We do not recommend inhalation during movement. During physical activity, the breathing pattern often changes to faster and shallower breathing. This can alter the distribution of aerosol particles within the airways.

For the most even inhalation, the animal should therefore stand still during the application. Movement after inhalation is generally possible with a time delay. However, immediately after the application, a short rest period is recommended first.

Ultrasonic nebulizers are used for nebulizing inhalation solutions in the field of respiratory applications. Aerosol generation occurs through mechanical vibrations at a frequency of 1.7 MHz, which are produced in distilled water (contact water). These vibrations are created by piezoceramic components that convert electrical energy into mechanical vibrations.

An aquapak® system is used within the contact liquid to physically separate the nebulizer from the nebulization unit. The generated vibrations are transmitted through its base and then spread through the inhalation liquid.

Fine capillary waves form on the surface of the NaCl or inhalation solution, which intensify with increasing excitation frequency and enable the formation of an aerosol.

The ultrasonic nebulizers of the equosonic series produce particle sizes of approximately 0.5 to 5 µm with a nebulization rate of up to 5.5 ml/min. For average-sized horses, a rate of about 4 ml/min is often used. The generated aerosol can distribute in different areas of the respiratory tract depending on particle size, breathing technique, and application situation.

Compared to technically simpler compressor nebulizers, ultrasonic nebulizers operate with high-frequency mechanical vibrations and thus produce a fine aerosol spectrum. Over 95% of the surface of the respiratory system is located below the larynx. The bronchial system has extremely fine branches with very small diameters. Therefore, particle size plays a crucial role in the distribution of aerosol particles within the airways.

In the scientific literature, particle sizes under 5 µm are described in connection with applications where aerosol particles can also reach deeper areas of the respiratory system. This means that a large proportion of the generated aerosol particles should be in the range below 5 µm.

The package includes:

• Equosonic Private

• 6 meters of tubing for 3 sets of 2 meters each

• Extra-large inhalation mask 12 liters or normal 9 liters or small 7 liters (please select)

• 2 inhalation capsules

• Disinfectant cleaner 1000 ml

• Pharmaceutical salt approx. 100 g

• Pharmaceutical saline 2% 1000 ml

• Sampling spikes and syringes

• 3 pcs. connection hose (fan to inhalation capsule)

Technical data:

• Particle size 0.5-5 microns (fully lung-penetrating)

• Nebulizer output approx. 4 ml/min

• Power approx. 80 watts

• Operating voltage 230 volts 50 Hz

What you still need to get started:

• approx. 500 ml distilled water

Please select the correct mask size for your horse:

12l volume for very large horses Dimensions: 28 cm opening x 19.5 cm base x 29 cm height, opening circumference about 85 cm, base circumference about 61 cm, suitable for large horse breeds or short, powerful noses (Shire horses, etc.)

9l volume for normal horses Dimensions: 26 cm opening x 19 cm base x 24 cm height, opening circumference about 80 cm, base circumference about 58 cm, suitable for most horse breeds such as warmbloods, larger riding ponies, Haflingers, etc.

7l volume for small horses Dimensions: 23 cm opening x 17 cm base x 21 cm height, opening circumference about 72 cm, base circumference about 53 cm, suitable for small to medium ponies

Our ultrasonic nebulizers of the equosonic series (Private, Clinic) operate with a ceramic membrane vibration frequency of 1.7 MHz. This produces durable particles in a size range of 0.5 – 5 µm (microns).
Due to the high airflow speeds in the fine bronchioles, effective inhalation must be calm, i.e., with a low breathing rate. The animal should not be moved beforehand, and immediate movement after treatment is not advisable.

The open mask

Our inhalation mask is made of high-quality, food-grade PE plastic in bucket shape and does not require additional valves. Unlike closed mask systems, the animal does not have to actively inhale the aerosol mist. Instead, the generated mist is continuously directed into the mask via a ventilation system.

The open system allows for the most natural and relaxed breathing possible during use. A calm breathing situation can help aerosol particles distribute evenly in the airways. Due to the lower breathing speed during relaxed breathing, fine aerosols can also reach deeper areas of the respiratory tract.

Our inhalers continuously introduce the aerosol into the mask while the horse can inhale and exhale the mist calmly.

Inhalation during movement

We do not recommend inhalation during movement. Physical activity often changes the breathing pattern to faster and shallower breathing. This can alter the distribution of aerosol particles within the airways.

For as even inhalation as possible, the horse should stand as calmly as possible during the application. Movement after inhalation is generally possible with some time delay. However, immediately after the application, a short rest period of about 15 minutes is recommended. Regular exercise is important for horses in general but should not be combined directly with inhalation.

Ultrasonic nebulizers are used for nebulizing inhalation solutions in the field of respiratory application. Aerosol generation occurs through mechanical vibrations at a frequency of 1.7 MHz, which are produced in distilled water (contact water). These vibrations are created by piezoceramic components that convert electrical energy into mechanical vibrations.

An aquapak® system is used within the contact liquid to physically separate the nebulizer from the nebulization unit. The generated vibrations are transmitted through its base and then spread through the inhalation liquid.

Fine capillary waves form on the surface of the NaCl or inhalation solution, which increase with rising excitation frequency and support the formation of an aerosol.

The package includes:

• Equosonic Clinic
• 6-meter hose for 3 sets of 2 meters each
• Inhalation mask extra large 12 liters or normal 9 liters or small 7 liters (Please select)
• 2 inhalation capsules
• Disinfectant cleaner 1000ml
• Pharmaceutical salt approx. 100 g
• Pharmaceutical saline 2% 1000 ml

• Sampling spikes and syringes
• 3 pcs. connecting hose (fan to inhalation capsule)

Technical data:

• Particle size 0.5-5 microns (fully lung-penetrating)
• Nebulizer output approx. 5.5 ml/min
• Power approx. 80 watts
• Operating voltage 230 volts 50Hz

What you still need to get started:

• approx. 500ml distilled water

Please select the correct mask size for your horse:

12l volume for very large horses Dimensions: 28cm opening x 19.5cm base x 29cm height, opening circumference about 85cm, base circumference about 61cm, suitable for large horse breeds or short, powerful noses (Shire horses, etc.)

9l volume for normal horses Dimensions: 26cm opening x 19cm base x 24cm height, opening circumference about 80cm, base circumference about 58cm, suitable for most horse breeds such as warmbloods, larger riding ponies, Haflingers, etc.

7l volume for small horses Dimensions: 23cm opening x 17cm base x 21cm height, opening circumference about 72cm, base circumference about 53cm, suitable for small to medium ponies

The ultrasonic nebulizers of the equosonic series generate aerosol particles in a size range of approx. 0.5 to 5 µm with a nebulization output of up to 5.5 ml/min. For normally sized horses, a performance of about 4 ml/min is often already used. The generated aerosol can distribute in different areas of the respiratory tract depending on particle size, breathing technique, and application situation.

Compared to technically simpler compressor nebulizers, ultrasonic nebulizers work with high-frequency mechanical vibrations and thus produce a fine aerosol spectrum. Since a large part of the surface of the respiratory system is located in the bronchial and alveolar area, particle size plays a crucial role in distribution within the airways.

Over 95% of the surface of the respiratory system is located below the larynx. The bronchial system has extremely fine branches with bronchi in the diameter range of a human hair. In the specialist literature, particle sizes under 5 µm are described in connection with applications where aerosol particles can also reach deeper areas of the respiratory system. This means that a large proportion of the generated aerosol particles should be in the range below 5 µm.

The ultrasonic nebulizers of the equosonic Private and equosonic Clinic series operate with a vibration frequency of the ceramic membrane of 1.7 MHz and generate aerosol particles in a size range of approx. 0.5 to 5 µm.

For as even a distribution of the aerosol as possible, a calm application situation with relaxed breathing and low respiratory rate is recommended. Therefore, the animal should preferably not be moved immediately before the application. Also, a short rest period is recommended immediately after inhalation.

The open mask

Our inhalation mask is made of high-quality, food-safe PE plastic in a bucket shape and does not require additional valves. Unlike closed mask systems, the animal does not have to actively inhale the aerosol mist. Instead, the generated mist is continuously directed into the mask via a ventilation system.

The open system allows for as natural and relaxed breathing as possible during the application. A calm breathing situation can help aerosol particles distribute evenly in the airways. Due to the lower breathing speed during relaxed breathing, fine aerosols can also reach deeper areas of the respiratory tract.

Our inhalers continuously introduce the aerosol into the mask while the horse can inhale and exhale the mist calmly.

Inhalation during movement

We do not recommend inhalation during movement. During physical activity, the breathing pattern often changes to faster and shallower breathing. This can alter the distribution of aerosol particles within the airways.

For as even inhalation as possible, the horse should stand as calmly as possible during the application. Movement after inhalation is generally possible with some time delay. However, immediately after the application, a short rest period of about 15 minutes is recommended. Regular exercise is generally important for horses but should not be combined immediately with inhalation.
