Kendall Aerodyne Omega Plus Starter Package Human Medicine

The model Kendall Aerodyne Omega Plus is a high-performance model from human medicine and is available from us at an unbeatable price. Only while supplies last.

Ultrasonic nebulizers are used for the treatment of all diseases of the respiratory tract, of various origins. The mist generation occurs through mechanical vibrations of 1.7 MHz (medical ultrasonic nebulizers), which are produced in distilled water (contact water). These vibrations are generated by piezoceramic components that convert electrical vibrations into mechanical ones. To provide physical separation between the medical nebulizer and the nebulization unit, an aquapak® system is used in the contact liquid. The mechanical vibrations penetrate its bottom and spread out in the inhalation liquid.

"They lead to the formation of capillary waves on the surface of the NaCl/medication solution, which rise exponentially with increasing excitation frequency."

This device operates with a power of up to 4ml/min ml/Min. It reaches both the upper and lower respiratory tracts. This distinguishes ultrasonic nebulizers from the technically simpler compressor nebulizers, as the functional main part of the respiratory tract with its very large surface area (bronchial system, alveolar system of the lung) is fully reached.

The bronchial system has bronchi in its finest branches with a diameter of a human hair, and a targeted application of nebulized substances must pass a threshold smaller than 5/1000 mm (5 microns) to reach the structures of the alveoli (air sacs).
This implies that the majority of the nebulized particles must be smaller than 5 microns.

The ultrasonic nebulizer of the Kendall Aerodyne Omega Plus operates with a vibration frequency of the ceramic membrane of 1.7 MHz. This generates durable particles in a size range of 0.5 – 6 µm (Micron).
Due to the high ventilation speeds in the fine bronchioles, effective inhalation must occur calmly, that is, with a low breathing frequency.
